| Type |
36 x 24 mm CMOS |
| Effective Pixels |
Approx. 24.1 megapixels |
| Total Pixels Approx |
26.7 megapixels |
| Aspect Ratio |
3:2 |
| Low-Pass |
Filter Built-in/Fixed |
| Sensor Cleaning |
EOS integrated cleaning system |
| Colour Filter Type |
Primary Colour |
| Sensor Shift IS |
Yes, up to 8-Stops advantage depending on the lens used |
| Type |
DIGIC X |
| Lens Mount |
RF (EF and EF-S lenses can be attached using EF TO |
| |
EOS R ADAPTER, EF TO EOS R ADAPTER WITH |
| |
CONTROL RING, EF TO EOS R Drop in filter ADAPTER |
| |
EF-M lenses not compatible) |
| Focal Length |
Equivalent to 1.0x the focal length of the lens with RF |
| |
and EF lenses 1.6x with EF-S |
| Type |
Dual Pixel CMOS AF II |
| AF System/Points |
With Area 100% horizontal and 100% vertical (Auto selection) 2 |
| |
100% horizontal and 90% vertical (manual selection)2 |
| AF working range |
EV -7.5 – 20 (at 23°C & ISO100)3 |
| AF Modes |
One Shot |
| |
Servo AF |
| AF Point Selection |
Automatic selection: 1053 Available AF areas when automatically selected |
| |
Manual selection- 1-point AF (AF frame size can be changed) 4779 AF positions available stills (3969 Movies) |
| |
Manual selection: AF point Expansion 4 points (up, down, left, right) |
| |
Manual selection: AF point Expansion surrounding |
| |
Manual selection: Flexible Zone AF 1-3 (all AF points |
| |
divided into minimum 9 to 999 maximum focusing zones) |
| AF Tracking |
Humans, Animals (Dogs, Cats and Birds) or Vehicles (Racing cars or Motor bikes), |
| AF Lock |
Locked when shutter button is pressed halfway or AF |
| |
ON is pressed in One Shot AF mode. Using |
| |
customised button set to AF stop in AI servo |
| AF Assist Beam |
Emitted by built in LED or optional dedicated Speedlite (flash) |
| Manual Focus |
Selected on lens |
| Metering modes |
Real-time with image sensor, 384-zone metering. |
| |
(1)Evaluative metering (linked to All AF points) |
| |
(2)Partial metering |
| |
(Approx. 5.9% of viewfinder at centre) |
| |
(3)Spot metering: Centre spot metering |
| |
(Approx. 2.9% viewfinder at centre) |
| |
AF point-linked spot metering not provided |
| |
(4)Centre weighted average metering |
| Metering Brightness Range |
EV -3 – 20 (at 23°C, ISO100, with evaluative metering) |
| AE Lock |
Auto: AE lock takes effect when focus is achieved |
| |
Manual: By AE lock button in P, Av, Fv, Tv and M modes |
| Exposure Compensation |
+/-3 EV in 1/3 or 1/2 stop increments (can be combined with AEB) |
| AEB |
+/-3 EV in 1/3 or 1/2 stop increments |
| Anti-flicker shooting |
Yes. Flicker detected at a frequency of 100 Hz or 120 |
| |
Hz. Maximum continuous shooting speed may decrease available with both electronic and |
| |
mechanical shutter |
| |
High Frequency anti flicker shooting for M and TV modes |
| ISO Sensitivity |
Auto 100-102400 (in 1/3-stop or whole stop increments) |
| |
ISO can be expanded to L:50, H1:204800, 4 |
| Type |
Electronically controlled focal-plane shutter and Electronic shutter function in sensor |
| Speed |
Mechanical: 30-1/8000 sec (1/2 or 1/3 stop increments), Bulb Electronic: 30-1/64000 |
| |
(1/2 or 1/3 stop increments up to 1/16000 then 1 stop until 1/64000) |
| |
(Total shutter speed range. Available range varies by shooting mode) |
| Shutter Release |
Soft touch electromagnetic release |
| Type |
Auto white balance with the imaging sensor |
| Settings |
AWB (Ambience priority/White priority), Daylight, |
| |
Shade, Cloudy, Tungsten light, White Fluorescent |
| |
light, Flash, Custom, Colour Temperature Setting |
| |
White balance compensation: |
| |
1.Blue/Amber +/-9 |
| |
2.Magenta/Green +/-9 |
| Custom White Balance |
Yes, 5 setting can be registered |
| WB Bracketing |
+/-3 levels in single level increments |
| |
3, 2, 5 or 7 bracketed images per shutter release |
| |
Selectable Blue/Amber bias or Magenta/Green bias |
| Type |
0.5- inch OLED colour EVF |
| Dot count |
5.76 Million dots (1600x1200) |
| |
(Vertical/Horizontal) Approx. 100% Magnification Approx. 0.76x 5 |
| Eyepoint |
Approx. 23mm (from eyepiece lens centre) |
| Dioptre Correction |
-4 to +2 m-1 (dioptre) |
| Display performance |
Power saving: 59.94 fps Smooth 119.98 fps |
| Viewfinder Information |
AF point information, Eye Control pointer, Exposure level indicator, Shooting mode, ISO speed, Shutter |
| |
speed, Aperture, Number of remaining multiple exposures, Exposure compensation, HDR shooting, |
| |
Highlight tone priority, Multiple-exposure shooting, Multi Shot Noise Reduction, Number of self-timer |
| |
shooting, Digital Lens Optimizer, Maximum burst, AF method, Battery level, AF operation, Exposure |
| |
simulation, Drive mode, AEB, Metering mode, FEB, Anti-flicker shooting, Still photo cropping, Aspect |
| |
ratio, Auto Lighting Optimizer, AE lock, Picture Style, Flash-ready, White balance, Flash off, White balance |
| |
correction, FE lock, Image Quality, High-speed sync, Bluetooth function, Wi-Fi function, Multi-function lock |
| |
warning, Histogram, Electronic level, Lens information, focus distance scale, vertical exposure |
| |
scale, Grid |
| Depth of field preview |
Yes, via customised button |
| Type |
8.01 cm (3.2") Clear View LCD II, |
| |
Approx. 4.15 million dots |
| Coverage |
Approx. 100% |
| Viewing Angle horizontally/ vertically |
Approx. 170° vertically and horizontally |
| Coating |
Anti-smudge. |
| Brightness Adjustment |
Manual: Adjustable to one of seven levels |
| |
Colour Tone Adjustment: 4 settings |
| Touch-screen operations |
Capacitive method with menu functions, Quick Control settings, playback operations, and |
| |
magnified display. AF point selection in still and Movies, touch shutter is possible in still photo shooting. |
| Display Options |
(1)Basic Camera settings |
| |
(2)Advance Camera settings |
| |
(3)Camera settings plus histogram and dual level display |
| |
(4)No info |
| |
(5)Quick Control Screen |
| |
(6)Display off |
| Modes |
E-TTL II Auto Flash, Metered Manual |
| X-sync |
1/200sec mechanical shutter / 1/250th electronic |
| |
1st curtain, 1/180sec Electronic shutter |
| Flash Exposure Compensation |
+/- 3EV in 1/3 increments with EX series Speedlite flashes |
| Flash Exposure Bracketing |
Yes, with compatible External Flash |
| Flash Exposure Lock |
Yes |
| Second Curtain Synchronisation |
Yes, via Speedlite |
| Multi-Function shoe/ Hot Shoe/PC terminal |
Yes/Yes/Yes |
| External Flash Compatibility |
E-TTL II with EX series Speedlite, wireless multi-flash support |
| External Flash Control |
via camera menu screen |
| Modes |
Stills; Flexible priority AE, Program AE, Shutter priority |
| |
AE, Aperture priority AE, Manual, Bulb and Custom (x3) |
| |
Movie: Program AE, Shutter priority AE, Aperture priority AE, Manual, and Custom (x3) |
| Picture Styles |
Auto, Standard, Portrait, Landscape, Fine Detail, Neutral, Faithful, Monochrome, User Defined (x3) |
| Colour Space |
sRGB and Adobe RGB |
| Image Processing |
Highlight Tone Priority (2 settings) |
| |
Auto Lighting Optimizer (4 settings) |
| |
Long exposure noise reduction |
| |
Clarity |
| |
High ISO speed noise reduction (4 settings) |
| |
(still and video) |
| |
Lens optical correction: |
| |
Peripheral illumination correction, Chromatic |
| |
aberration correction Distortion correction |
| |
(during/after still photo shooting, during video only) |
| |
Diffraction correction, |
| |
Digital Lens Optimizer |
| |
(during/after still photo shooting) |
| |
Resize to M, S1, S2 |
| |
Cropping: JPEG images can be cropped |
| |
(Aspect ratios 3:2, 4:3, 16:9, 1:1) |
| |
Cropping of images |
| |
Switch between vertical and horizontal cropping orientation |
| |
Image straightening |
| |
Cropping frame can be moved using touch screen operation |
| |
RAW image processing |
| |
Multiple exposure |
| |
HDR |
| |
HEIF to Jpeg conversion |
| Drive modes |
Single, Continuous High+, Continuous High, Continuous Low, Self-timer (2s+remote, 10s+remote) |
| Continuous Shooting |
Max. Approx. 12 fps. with Mechanical shutter/1st curtain electronic speed maintained for 1000+ JPEG |
| |
or 1000 RAW images or 30 FPS with electronic shutter speed maintained for 540 JPEG or 150 RAW images 6 |
| |
Interval timer Built in |
| Still Image Type |
RAW 14 bit: RAW and C-RAW (Canon original RAW 3rd edition) |
| |
JPEG 8 bit: 10 compression options |
| |
HEIF 10 bit: 10 compression options |
| |
Complies with Exif 2.31 and Design rule for Camera |
| |
File system 2.0 |
| |
Complies with Digital Print Order Format [DPOF] |
| |
Version 1.1 |
| RAW+JPEG/HEIF simultaneous recording |
Yes, any combination of RAW + JPEG or RAW + HEIF possible, |
| |
Image Size RAW/ C-RAW 3:2 ratio 6000x4000, 1.6x (crop) 3744x2496 |
| |
JPEG/ HEIF: |
| |
3:2 ratio (L,) 6000x4000, (M) 3984x2656, (S1) 2976x1984, |
| |
(S2) 2400x1600 |
| |
1.6x (crop) (L) 3744x2496, (S2) 2400x1600 |
| |
4:3 ratio (L) 5328x4000, (M) 3552x2664, (S1) 2656x1992, |
| |
(S2) 2112x1600 |
| |
16:9 ratio (L) 6000x3368, (M) 3984x2240, (S1) |
| |
2976x1680, (S2) 2400x1344 |
| |
1:1 ratio (L) 4000x4000, (M) 2656x2656, (S1) 1984x1984, |
| |
(S2) 1600x1600 |
| Folders |
New folders can be manually created, named and |
| File Numbering |
(1)Consecutive numbering |
| |
(2)Auto-reset |
| |
(3)Manual reset |
| |
File naming 2 User Presets |
| EOS MOVIE |
Movie Type MP4 Video: 4K DCI/ UHD (17:9 / 16:9), Full HD (16:9) |
| |
4K/ Full HD: AVC/H.265 variable (average) bit rate, |
| |
Audio: Linear PCM |
| |
4K/ Full HD: MPEG4 AVC/H.264 variable (average) bit rate, |
| |
Audio: Linear PCM |
| |
6K RAW: 12-bit CRM Audio: Linear PCM |
| |
Movie Size 7 6K DCI (17:9) 6000 x 3164 (59.94, 50, 29.97, 25, 24, 23.98fps) RAW |
| |
4K DCI (17:9) 4096 x 2160 (59.94, 50, 29.97, 25, 24, 23.98 fps) intra or inter frame / light inter frame |
| |
(4K UHD (16:9) 3840 x 2160 (119.9, 100, 59.94, 50, 29.97, 25, 23.98 fps) intra or inter frame |
| |
Full HD (16:9) 1920 x 1080 (119.9, 100, 59.94, 50, 29.97, 25, 23.98 fps) intra or inter frame |
| |
Full HD (16:9) 1920 x 1080 HDR (29.97, 25 fps) inter frame, |
| Colour Sampling (Internal recording) |
6K RAW 12bit, 4K/ Full HD - YCbCr4:2:0 8-bit or |
| |
YCbCr4:2:2 10bit |
| Canon Log |
Yes, Canon Log 3 |
| Movie Length |
Max duration 6 hours. (excluding High Frame Rate |
| |
movies). No 4 GB file limit with exFAT formatted card. 8 |
| High Frame Rate Movie |
MOV Video: 4K – DCI 4096x2160 / UHD 3840x2160/ |
| |
Full HD 1920 x1080 at 100 fps or 119.9 fps 9 |
| |
Recorded as 1/4-speed slow motion movie |
| Frame Grab |
10 8.8-megapixel JPEG still image frame grab from 4K DCI movie possible 8.3-megapixel JPEG still image frame grab from 4K |
| |
UHD movie possible |
| |
(HEIF only possible when HDR PQ is set) |
| Bitrate/Mbps |
CRM- |
| |
6K RAW (59.97p/50p): Approx. 2600 Mbps |
| |
6K RAW (29.97p/25.00p/): Approx. 2000 Mbps |
| |
6K RAW (24.00p/23.98p): Approx. 1600 Mbps |
| |
6K C-RAW (59.97p/50p): Approx. 1800 Mbps |
| |
6K C-RAW (29.97p/25.00p): Approx. 900 Mbps |
| |
6K C-RAW (24.00p/23.98p): Approx. 720 Mbps |
| |
MOV: MP4 H.264 Canon Log off: |
| |
4K DCI/UHD (119.9p / 100p): Approx. 1880 Mbps |
| |
4K DCI/UHD (59.94p/50.00p): ALL-I Approx. 940 Mbps |
| |
4K DCI/UHD (59.94p/50.00p): IPB Approx. 230 Mbps |
| |
4K DCI/UHD (59.94p/50.00p): IPB Light Approx.120 Mbps |
| |
4K DCI/UHD (29.97p/25.00p/24.00p/23.98p): ALL-I Approx. 470 Mbps |
| |
4K DCI/UHD (29.97p/25.00p/24.00p/23.98p): IPB Approx. 120 Mbps |
| |
4K DCI/UHD (29.97p/25.00p/24.00p/23.98p): IPB Light Approx. 60 Mbps |
| |
Full HD (119.9p / 100p): Approx. 360 Mbps |
| |
Full HD (59.94p/50.00p): ALL-I Approx. 180 Mbps |
| |
Full HD (59.94p/50.00p): IPB Approx. 60 Mbps |
| |
Full HD (59.94p/50.00p): IPB light Approx. 35 Mbps |
| |
Full HD (29.97p/25.00p/24.00p/23.98p):ALL-I Approx. 90 Mbps |
| |
Full HD (29.97p/25.00p/24.00p/23.98p): IPB Approx.30 Mbps |
| |
Full HD (29.97p/25.00p/24.00p/23.98p): IPB Light |
| |
Approx. 12 Mbps |
| |
MOV: MP4 H.265 Canon Log on |
| |
4K DCI/UHD (119.9p / 100p): Approx. 1880 Mbps |
| |
4K DCI/UHD (59.94p/50.00p): ALL-I Approx. 1000 Mbps |
| |
4K DCI/UHD (59.94p/50.00p): IPB Approx. 340 Mbps |
| |
4K DCI/UHD (59.94p/50.00p): IPB Light Approx. 170 Mbps |
| |
4K DCI/UHD (29.97p/25.00p/24.00p/23.98p): ALL-I Approx. 470 Mbps |
| |
4K DCI/UHD (29.97p/25.00p/24.00p/23.98p): IPB Approx. 170 Mbps |
| |
4K DCI/UHD (29.97p/25.00p/24.00p/23.98p): IPB Light Approx. 85 Mbps |
| |
Full HD (119.9p / 100p): Approx. 470 Mbps |
| |
Full HD (59.94p/50.00p): ALL-I Approx. 230 Mbps |
| |
Full HD (59.94p/50.00p): IPB Approx. 90 Mbps |
| |
Full HD (59.94p/50.00p): IPB light Approx. 50 Mbps |
| |
Full HD (29.97p/25.00p/24.00p/23.98p):ALL-I Approx. 135 Mbps |
| |
Full HD (29.97p/25.00p/24.00p/23.98p): IPB Approx. 45 Mbps |
| |
Full HD (29.97p/25.00p/24.00p/23.98p): IPB Light Approx. 28 Mbps |
| Dual recording |
Yes |
| Microphone |
Built-in mono microphone |
| |
(48 KHz, 16-bit x 2 channels) |
| HDMI Display |
Output to external monitor only (output of images and shooting information, images are recorded to |
| |
the card) Camera screen and External Monitor output (Simultaneous recording to camera and |
| |
external recorder, camera screen shows images with shooting information) |
| HDMI Output |
4K (DCI) 59.94p / 50.00p/29.97p /25.00p/24.00p/ |
| |
23.98p, 4K (UHD) 59.94p / 50.00p/ 29.97p / 25.00p / |
| |
23.98p, Full HD 59.94p / 59.94i, 50.00p / 50.00i 480p |
| |
59.94p 576p 50p Uncompressed YCbCr 4:2:2, 8-bit or |
| |
10-bit, sound output via HDMI is also possible |
| Focusing |
Dual Pixel CMOS AF II with Eye/Face Detection and |
| |
Tracking AF (people, animals and vehicles), Movie |
| |
Servo AF |
| |
Manual Focus |
| ISO Auto |
100-25600, H: up to 102400 |
| |
Manual: 100-25600, H: up to 102400, |
| Metadata Tag |
User copyright information (can be set in camera) |
| |
Image rating (0-5 stars) |
| |
IPTC data (registered with EOS Utility) |
| |
IPTC data (via MFT app) |
| |
Image transfer with caption |
| |
(Caption registered with EOS Utility) |
| LCD Panel/Illumination |
Yes/Yes |
| Water/Dust resistance |
Yes |
| Voice Memo |
Yes |
| Intelligent Orientation Sensor |
Yes |
| Playback zoom |
1.5x - 10x in 15 steps |
| Display Formats |
(1)Single image |
| |
(2)Single image with information (2 levels) |
| |
Basic - Shooting information (shutter speed, aperture,ISO and Image quality) |
| |
Detailed - Shooting information (shutter speed,aperture, ISO, metering Image, quality and file size), |
| |
Lens information, Brightness and RGB histogram, |
| |
White balance, Picture Style, Color space and noise |
| |
reduction, Lens optical correction, GPS information, IPTC information |
| |
(3)4 image index |
| |
(4)9 image index |
| |
(5)36 image index |
| |
(6)100 image index |
| |
(7)Jump Display (1, 10 or 100 images, start of burst sequence Date, Folder, Movies, Stills, Protected |
| |
images, Rating) |
| |
(8)Movie edit |
| |
(9)RAW processing |
| |
(10)Rating |
| Slide Show |
Image selection: All images, by Date, by Folder, |
| |
Movies, Stills, Protected images or Rating |
| |
Playback time: 1/2/3/5/10 or 20 seconds |
| |
Repeat: On/Off |
| Histogram |
Brightness: Yes |
| |
RGB: Yes |
| Highlight Alert |
Yes |
| Image Erase |
Single image, select range, Selected images, Folder,Card |
| Image Erase Protection |
Erase protection of Single image, Folder or Card all found images (only during image search) |
| |
Self-Timer 2 or 10 sec. |
| Menu Categories |
(1)Shooting menu |
| |
(2)AF Menu |
| |
(3)Playback menu |
| |
(4)Network |
| |
(5)Setup menu |
| |
(6)Custom Functions menu |
| |
(7)My Menu |
| |
English, German, French, Dutch, Danish, Portuguese, |
| |
Finnish, Italian, Norwegian, Swedish, Spanish, Greek, |
| |
Russian, Polish, Czech, Hungarian, Vietnamese, Hindi, |
| |
Romanian, Ukrainian, Turkish, Arabic, Thai, Simplified |
| |
Chinese, Traditional Chinese, Korean, Malay, |
| |
Indonesia and Japanese |
| Firmware Update |
Update possible by the user via menu or Camera |
| |
connect App (Camera, Lens, External Speedlite, BLEremote control, Lens adapter) |
| Computer |
SuperSpeed USB 3.2 Gen 2 USB C connector |
| |
Wi-Fi Wireless LAN (IEEE802.11a/b/g/n/AC) |
| |
(5 GHz /2.4 GHz)12, with Bluetooth 5.0 support |
| |
Features supported - EOS Utility, Smartphone, Upload |
| |
to image.canon, Wireless printing |
| Other |
HDMI mini out (Type D, HDMI-CEC compatible), |
| |
External Microphone In/Line In (Stereo mini jack), |
| |
Headphone socket (Stereo mini jack), N3-type terminal (remote control terminal) |
| PictBridge |
Not supported |
| Type |
1x CFexpress type B |
| |
1x SD/SDHC/SDXC and UHS-II |
| PC & Macintosh |
Windows 8.1 and Windows 10 |
| |
(tablet mode not supported) |
| |
OS X v10.12, 10.13, 10.14, 10.15. OS 11 |
| Image Processing |
Digital Photo Professional 4.15.1 or later Digital Photo |
| |
Professional Express mobile app (iOS only) |
| Other |
EOS Utility 3 (incl. Remote Capture), Picture Style |
| |
Editor, WFT Utility, EOS Lens Registration Tool, EOS Web Service Registration Tool, Canon Camera |
| |
connect app (iOS/Android), Mobile File Transfer app (iOS/Android), |
| Batteries |
Rechargeable Li-ion Battery LP-E19 (supplied) |
| Battery life |
With LCD Approx.860 shots (at 23°C) |
| |
With Viewfinder Approx. 620 shots (at 23°C) 13 |
| Battery Indicator |
6 levels + percentage |
| Power saving Power |
turns off after 15 seconds, 30 seconds, 1, 3, 5, 10 or 30 mins |
| Power Supply & Battery Chargers |
Battery charger LC-E19E (supplied), AC Adapter |
| |
AC-E19 and DC Coupler DR-E19, PD-E1 USB power adapter |
| Body Materials |
Magnesium Alloy body and polycarbonate with |
| |
glass fibre |
| Operating Environment |
0 – 40 °C, 85% or less humidity |
| Dimensions |
(WxHxD) 150x 142.6 x 87.2mm |
| Weight |
(body only) Approx. 822 g (1015g with card and battery) |
| Wireless File Transmitter |
None |
| Lenses |
All RF lenses (EF & EF-S via Lens adapters) |
| Lens adapters |
EF TO EOS R ADAPTER, EF TO EOS R ADAPTER WITH |
| |
CONTROL RING, EF TO EOS R Drop in filter ADAPTER |
| Flash |
Canon Speedlite (EL-114, EL-100, 90EX, 220EX, 270EX, |
| |
270EX II, 320EX, 380EX, 420EX, 430EX, 430EX II, 430EX III |
| |
470EX-AI, 550EX, 580EX14, 580EX II14, 600EX14, |
| |
600EX-RT14, 600EX-II-RT14, Macro-Ring-Lite MR-14EX, |
| |
Macro Ring Lite MR-14EX II, Macro Twin Lite MT-24EX, |
| |
Macro Twin Lite MT-26EX Speedlite Transmitter ST-E2, |
| |
Speedlite Transmitter ST-E3-RT14, Speedlite Transmitter |
| |
ST-E3-RT V214, Speedlite Transmitter ST- E10) |
| Remote Controller/Switch |
Remote control with N3 type socket, Speedlite |
| |
600EX-II-RT. Speedlite EL-1 and BR-E1 Bluetooth remote |
| Other |
Eyecup ER-h, Eyecup ER-hE, Multi-Function Shoe |
| |
Adapter AD- E1, Multi-Function Shoe Directional |
| |
Stereo Microphone DM-E1D (Mic), Multi-Function |
| |
Shoe Adapter for Smartphone Link AD-P1 for Android |
| |
(phone holder), Stereo Microphone DM-E1 / DM-E100 |
